Juniper Networks (Junior)

[Juniper#009] OSPF Multi-Area Basic 설정

R1: set interfaces ge-0/0/0 unit 0 family inet address 10.1.1.1/30 set interfaces lo0 unit 0 family inet address 1.1.1.1/32 R2: set interfaces ge-0/0/0 unit 0 family inet address 10.1.1.2/30 set interfaces ge-0/0/1 unit 0 family inet address 10.2.2.1/30 set interfaces ge-0/0/2 unit 0 family inet address 10.3.3.1/30 set interfaces lo0 unit 0 family inet address 2.2.2.2/32 R3: set interfaces ge-0/..

2023. 6. 21. 12:31
Juniper Networks (Junior)

[Juniper#008] OSPF Basic 설정

[인터페이스설정] R1: set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.1/30 set interfaces ge-0/0/1 unit 0 family inet address 10.1.1.1/24 R2: set interfaces ge-0/0/0 unit 0 family inet address 1.1.1.2/30 set interfaces ge-0/0/2 unit 0 family inet address 2.2.2.1/30 R3: set interfaces ge-0/0/2 unit 0 family inet address 2.2.2.2/30 set interfaces ge-0/0/3 unit 0 family inet address 172.16.0.1/30 ..

2023. 6. 21. 12:29
Juniper Networks (Junior)

[Juniper#007] VRRPv2 설정

주니퍼 방화벽 설정(SRX320) – ge-0/0/0 IP : 192.168.20.11 #set interfaces ge-0/0/0 unit 0 family inet address 192.168.20.11/24 vrrp-group 1 virtual-address 192.168.20.254 #set interfaces ge-0/0/0 unit 0 family inet address 192.168.20.11/24 vrrp-group 1 priority 200 ##set security zones security-zone trust interfaces ge-0/0/0 // 안치면 SRX에서 핑 안나감 루커스 스위치 설정(ICX7150) – eth1/1/1 IP : 192.168.20.12 Router vrrp..

2023. 6. 21. 12:27
Juniper Networks (Junior)

[Juniper#006] VSTP 설정(feat. PVST+)

set protocols vstp interface all set protocols vstp vlan all interface all 또는, edit protocols vstp 적용 후, set interface all set vlan all interface all 결과 동일 “VSTP 및 RSTP는 디바이스에서 동시에 구성할 수 있는 유일한 스패닝 트리 프로토콜니다.” Rapid PVST + 를 사용하려면 두개다 적용하는 것이 좋다. # delete protocols rstp force-version stp //강제로 rstp 사용안함 # delete protocols vstp force-version stp //강제로 vstp 사용안함

2023. 6. 21. 12:23
Juniper Networks (Junior)

[Juniper#005] Static 설정

root# set routing-options static route 0.0.0.0/0 next-hop 192.168.10.5 // 디폴트 경로 설정 이하 시스코와 유사.

2023. 6. 21. 12:21
Juniper Networks (Junior)

[Juniper#004] VLAN 설정 및 RVI 설정

[시나리오] ge-0/0/0 to ge-0/0/5까지 range를 적용하여 vlan을 할당하고 SVI를 설정하여라. set vlans vlan10 vlan-id 10 set interfaces ge-0/0/0 unit 0 family ethernet-switching vlan members vlan10 set interfaces vlan unit 0 family inet address 192.168.10.1/24 set interfaces interface-range range10 member-range ge-0/0/0 to ge-0/0/5 set interfaces interface-range range10 unit 0 family ethernet-switching vlan members vlan10 ..

2023. 6. 21. 12:20
